DPI 705E
Price on request
The Druck DPI 705E Series of handheld pressure indicators combine tough and rugged design with accurate and reliable pressure measurement. New materials and technical innovations from over fifteen years experience with portable pressure testers has resulted in this advanced new product. Intrinsically safe (I.S.) versions are available certified to European and American standards for use in hazardous areas.
Anderen kochten ook:
- Product description
- Extra information
- Video
- Downloads
-
The Druck DPI 705E Series of handheld pressure and optional temperature indicators combine tough and rugged design with accurate and reliable measurements.
Compact and robust, the DPI 705E Series is designed for single handed operation and provides many essential features required for routine maintenance and system troubleshooting.
Features
- 48 pressure ranges from ±25 mbar to 1,400 bar(±1.69 psi to 20,000 psi / 2.5 KPa to 140 MPa)
- Total 1 year uncertainty down to 0.05% full scale (FS)over temperature range of -10°C to +50°C
- Integral calibration record with calibration duecount-down display
- Rugged, handheld design with backlit high-contrastdisplay
- Leak test, tare, maximum/minimum and filter
- Hazardous Area (Intrinsically safe) version available
- Optional remote plug and play pressure andResistance Temperature Detector (RTD) sensors
- Optional pneumatic and hydraulic hand pumps
Applications
The DPI 705 Series, used in conjunction with pneumatic or hydraulic pressure generators, is a simple, low cost solution complementing the wide range of Druck portable process calibrators
-
Pressure Ranges
Internal and remote sensors are fitted with pressure connectors as detailed below:
- 25 mbar – 200 bar (10 inH2O - 3000 psi / 2.5 kPa - 20 MPa): G1/8 BSP female
- Differential reference port: Legris 4 mm tubing adaptor
- ≥350 bar (5000 psi / 35 MPa): Autoclave 9/16 x 18 UNF Male
DPI 705E Internal Pressure Sensors
The DPI705E includes an internal Absolute, Gauge or Differential sensor.
Available ranges as per table:
Pressure Range
Abs
Gauge
Differential
Standard Accuracy
High Accuracy
25 mbar / 10 inH2O / 2.5 kPa
-
√
√
√
-
70 mbar / 1 psi / 7 kPa
-
√
√
√
-
200 mbar / 3 psi / 20 kPa
-
√
√
√
-
350 mbar / 5 psi / 35 kPa
√
√
√
√
√
700 mbar / 10 psi / 70 kPa
√
√
√
√
√
1 bar / 15 psi / 100 kPa
√
√
√
√
√
2 bar / 30 psi / 200 kPa
√
√
√
√
√
3.5 bar / 50 psi / 350 kPa
√
√
-
√
√
7 bar / 100 psi / 700 kPa
√
√
-
√
√
10 bar / 150 psi / 1000 kPa
√
√
-
√
√
20 bar / 300 psi / 2 MPa
√
√
-
√
√
35 bar / 500 psi / 3.5 MPa
√
√
-
√
√
70 bar / 1000 psi / 7 MPa
√
√
-
√
√
100 bar / 1500 psi / 10 MPa
√
√
-
√
√
135 bar / 2000 psi / 13.5 MPa
√
√
-
√
√
200 bar / 3000 psi / 20 MPa
√
√
-
√
√
350 bar / 5000 psi / 35 MPa
√
-
-
√
√
700 bar / 10000 psi / 70MPa
√
-
-
√
√
Note: Do not apply pressure greater than 1 bar (16 psi) absolute to the negative port of differential pressure indicators.
PM 700E External Remote Pressure Sensors
Any number of remote sensors can be used with a single DPI705E as all sensors hold their own calibration data and are supplied with a 2.9m (9.5 feet) cable
Available ranges as per table:
Pressure Range
Abs
Gauge
Differential
Standard
AccuracyHigh
Accuracy25 mbar / 10 inH2O / 2.5 kPa
-
√
√
√
-
70 mbar / 1 psi / 7 kPa
-
√
√
√
-
200 mbar / 3 psi / 20 kPa
-
√
√
√
-
350 mbar / 5 psi / 35 kPa
√
√
√
√
√
700 mbar / 10 psi / 70 kPa
√
√
√
√
√
1 bar / 15 psi / 100 kPa
√
√
√
√
√
2 bar / 30 psi / 200 kPa
√
√
√
√
√
3.5 bar / 50 psi / 350 kPa
√
√
-
√
√
7 bar / 100 psi / 700 kPa
√
√
-
√
√
10 bar / 150 psi / 1000 kPa
√
√
-
√
√
20 bar / 300 psi / 2 MPa
√
√
-
√
√
35 bar / 500 psi / 3.5 MPa
√
√
-
√
√
70 bar / 1000 psi / 7 MPa
√
√
-
√
√
100 bar / 1500 psi / 10 MPa
√
√
-
√
√
135 bar / 2000 psi / 13.5 MPa
√
√
-
√
√
200 bar / 3000 psi / 20 MPa
√
√
-
√
√
350 bar / 5000 psi / 35 MPa
√
-
-
√
√
700 bar / 10000 psi / 70 MPa
√
-
-
√
√
1000 bar/ 15000 psi/ 100 MPa
√
-
-
√
√
1400 bar/20000 psi/140 MPa
√
-
-
√
√
Accuracy Specification
Absolute Sensors
Standard Accuracy
High Accuracy
Pressure Range
NLH&R
Total Uncertainty
NLH&R
Total uncertainty
-10 to 50°C (14 to 122°F)
(% FS)
(% FS)
(% FS)
(% FS)
350 mbar to 1400 bar
0.08
0.1
0.04
0.075
Gauge/Differential Sensors
Standard Accuracy
High Accuracy Pressure Range
NLH&R
Total Uncertainty
NLH&R
Total Uncertainty
-10 to 50°C (14 to 122°F)
(% FS)
(% FS)
(% FS)
(% FS)
25 mbar
0.3
0.348
N/A
N/A
70 mbar
0.1
0.121
N/A
N/A
200 mbar
0.08
0.1
N/A
N/A
350 mbar to 700 mbar
0.08
0.1
0.04
0.05
1 bar to 200 bar
0.08
0.1
0.04
0.05
-
